The Foxflash ECU Programmer can support FCA GPEC2 GPEC3 GPEC4LM GPEC2A ECUs read and write in Boot mode since March 14, 2023.Click here to check the detailed ECU models. Today we’ll share the Pinout to these ECUs.
- BAM SPC5674 CONTINENTAL GPEC2A FCA Pinout
Connect with the multifunction cable the CNF1 on the PCB.
Use the driver:
→ TOOLS BOOT MODE
→ MOTOROLA FREESCALE BAM
→ CONTINENTAL GPEC2A
- BAM SPC5674 CONTINENTAL GPEC3 FCA Pinout
Connect with the multifunction cable the CNF1 on the PCB.
Use the driver:
→ TOOLS BOOT MODE
→ MOTOROLA FREESCALE BAM
→ CONTINENTAL GPEC3
- BAM SPC5674 CONTINENTAL GPEC4 FCA Pinout
Connect with the multifunction cable the CNF1 signal on the PCB.
Use the driver:
→ TOOLS BOOT MODE
→ MOTOROLA FREESCALE BAM
→ FCA CONTINENTAL GPEC4
- BAM SPC5674 CONTINENTAL GPEC4LM FCA Pinout
Connect with the multifunction cable the CNF1 signal on the PCB.
Use the driver:
→ TOOLS BOOT MODE
→ MOTOROLA FREESCALE BAM
→ FCA CONTINENTAL GPEC4LM
